Buffering when playing .ts files (also noticed my computer seems to cap the stream to around 15~Mbps)

_dstrukt.n1ne · November 25, 2017, 5:42am

I’m getting stuttering issues when playing back .ts files (due to high bitrate?) but I have more than enough external and internal bandwidth (802.11ac, CAT5e, Gigabit switches and router)

If I play it locally via my computer’s media player, it works flawlessly.

In the Task Manager, I noticed my ATV is only getting about ~15Mbps when there’s a LOT more bandwidth available. I can open a heavy bandwidth intensive app that saturates my network, but Infuse will stay around ~15Mbps

I just upgraded and installed 5.6.2.

mediainfo on the file in question


General
ID : 1 (0x1)
Complete name : **********************.ts
Format : MPEG-TS
File size : 16.6 GiB
Duration : 2h 9mn
Overall bit rate mode : Variable
Overall bit rate : 18.3 Mbps
Law rating : PG

Video
ID : 49 (0x31)
Menu ID : 1 (0x1)
Format : MPEG Video
Format version : Version 2
Format profile : Main@High
Format settings, BVOP : No
Format settings, Matrix : Custom
Format settings, GOP : M=3, N=15
Codec ID : 2
Duration : 2h 9mn
Bit rate : 16.6 Mbps
Maximum bit rate : 17.0 Mbps
Width : 1 920 pixels
Height : 1 080 pixels
Display aspect ratio : 16:9
Frame rate : 29.970 fps
Color space : YUV
Chroma subsampling : 4:2:0
Bit depth : 8 bits
Scan type : Interlaced
Scan order : Top Field First
Compression mode : Lossy
Bits/(Pixel*Frame) : 0.268
Time code of first frame : 00:00:00;00
Time code source : Group of pictures header
Stream size : 15.1 GiB (91%)

Audio #1
ID : 51 (0x33)
Menu ID : 1 (0x1)
Format : AC-3
Format/Info : Audio Coding 3
Mode extension : CM (complete main)
Format settings, Endianness : Big
Codec ID : 129
Duration : 2h 9mn
Bit rate mode : Constant
Bit rate : 384 Kbps
Channel(s) : 6 channels
Channel positions : Front: L C R, Side: L R, LFE
Sampling rate : 48.0 KHz
Bit depth : 16 bits
Compression mode : Lossy
Delay relative to video : 13ms
Stream size : 356 MiB (2%)
Language : English

Audio #2
ID : 52 (0x34)
Menu ID : 1 (0x1)
Format : AC-3
Format/Info : Audio Coding 3
Mode extension : VI (visually impaired)
Format settings, Endianness : Big
Codec ID : 129
Duration : 2h 9mn
Bit rate mode : Constant
Bit rate : 192 Kbps
Channel(s) : 2 channels
Channel positions : Front: L R
Sampling rate : 48.0 KHz
Bit depth : 16 bits
Compression mode : Lossy
Delay relative to video : 9ms
Stream size : 178 MiB (1%)
Language : enm

Audio #3
ID : 53 (0x35)
Menu ID : 1 (0x1)
Format : AC-3
Format/Info : Audio Coding 3
Mode extension : CM (complete main)
Format settings, Endianness : Big
Codec ID : 129
Duration : 2h 9mn
Bit rate mode : Constant
Bit rate : 192 Kbps
Channel(s) : 2 channels
Channel positions : Front: L R
Sampling rate : 48.0 KHz
Bit depth : 16 bits
Compression mode : Lossy
Delay relative to video : 8ms
Stream size : 178 MiB (1%)
Language : English

Text #1
ID : 49 (0x31)-1
Menu ID : 1 (0x1)
Format : EIA-708
Muxing mode : A/53 / DTVCC Transport
Muxing mode, more info : Muxed in Video #1
Duration : 2h 9mn
Bit rate mode : Constant
Stream size : 0.00 Byte (0%)

Text #2
ID : 49 (0x31)-2
Menu ID : 1 (0x1)
Format : EIA-708
Muxing mode : A/53 / DTVCC Transport
Muxing mode, more info : Muxed in Video #1
Duration : 2h 9mn
Bit rate mode : Constant
Stream size : 0.00 Byte (0%)

==================MPEG2Repair 1.0.1.5 Log===================

MPEG2Repair: ******************************.ts

Sequence Frame 16090(8-P) / Time 0:08:56 :
VideoError: Too many macroblocks in slice. MBA=1560(0,208)
VideoError: Missing 1 picture slices at MBA=1559(1904,192)
FileInfo: Last video errors span 855 bytes at file offset 1229286142
FileInfo: Last video errors span 1 bytes at file offset 1229288024

Sequence Frame 42312(5-P) / Time 0:23:31 :
VideoError: MPEG2 Intra DCT coefficient index out of bounds. MBA=5843(1328,768)
VideoError: Failed to decode macroblock at MBA=5843(1328,768)
FileInfo: Last video errors span 207 bytes at file offset 3233182330

Sequence Frame 50743(12-B) / Time 0:28:13 :
VideoError: MPEG2 Intra DCT coefficient index out of bounds. MBA=2754(1824,352)
VideoError: Failed to decode macroblock at MBA=2754(1824,352)
FileInfo: Last video errors span 58 bytes at file offset 3877454639

Sequence Frame 56613(5-P) / Time 0:31:29 :
VideoError: Invalid macroblock address increment. MBA=3010(160,400)
VideoError: Invalid macroblock address increment code. MBA=3011(176,400)
FileInfo: Last video errors span 1090 bytes at file offset 4325910442
VideoError: Invalid motion vector code. MBA=3431(1136,448)
VideoError: Failed to decode macroblock at MBA=3431(1136,448)
FileInfo: Last video errors span 163 bytes at file offset 4325915070

Sequence Frame 56639(13-B) / Time 0:31:29 :
AudioError: Corrupted AC3 frame of 1534 payload bytes at file offset 4327824694

Sequence Frame 63068(7-B) / Time 0:35:04 :
VideoError: Looking for next slice, found premature end of picture. Last slice=0
VideoError: Slice 227 does not begin where previous slice ended. MBA=27120(0,3616)
VideoError: Missing 8160 macroblocks in picture slice(s) at MBA=0(0,0).
FileInfo: Last video errors span 72 bytes at file offset 4819096720

Sequence Frame 63069(7-B) / Time 0:35:04 :
FileInfo: Last video errors span 10 bytes at file offset 4819096792
VideoWarning: Unexpected MPEG2 start code 000001b2 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096802
VideoWarning: Unexpected MPEG2 start code 00000101 skipped
FileInfo: Last video errors span 24 bytes at file offset 4819096814
VideoWarning: Unexpected MPEG2 start code 00000102 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096838
VideoWarning: Unexpected MPEG2 start code 00000104 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096850
VideoWarning: Unexpected MPEG2 start code 00000105 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096862
VideoWarning: Unexpected MPEG2 start code 00000106 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096878
VideoWarning: Unexpected MPEG2 start code 00000107 skipped
FileInfo: Last video errors span 27 bytes at file offset 4819096890
VideoWarning: Unexpected MPEG2 start code 00000108 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096917
VideoWarning: Unexpected MPEG2 start code 0000010a skipped
FileInfo: Last video errors span 12 bytes at file offset 4819096929
VideoWarning: Unexpected MPEG2 start code 0000010b skipped
FileInfo: Last video errors span 24 bytes at file offset 4819096941
VideoWarning: Unexpected MPEG2 start code 0000010c skipped
FileInfo: Last video errors span 21 bytes at file offset 4819096965
VideoWarning: Unexpected MPEG2 start code 0000010e skipped
FileInfo: Last video errors span 17 bytes at file offset 4819096986
VideoWarning: Unexpected MPEG2 start code 0000010f skipped
FileInfo: Last video errors span 15 bytes at file offset 4819097003
VideoWarning: Unexpected MPEG2 start code 00000110 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819097018
VideoWarning: Unexpected MPEG2 start code 00000111 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819097030
VideoWarning: Unexpected MPEG2 start code 00000112 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819097042
VideoWarning: Unexpected MPEG2 start code 00000113 skipped
FileInfo: Last video errors span 14 bytes at file offset 4819097054
VideoWarning: Unexpected MPEG2 start code 00000114 skipped
FileInfo: Last video errors span 24 bytes at file offset 4819097072
VideoWarning: Unexpected MPEG2 start code 00000115 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819097096
VideoWarning: Unexpected MPEG2 start code 00000146 skipped
FileInfo: Last video errors span 14 bytes at file offset 4819097108
VideoWarning: Unexpected MPEG2 start code 00000117 skipped
FileInfo: Last video errors span 25 bytes at file offset 4819097122
VideoWarning: Unexpected MPEG2 start code 00000118 skipped
FileInfo: Last video errors span 16 bytes at file offset 4819097147
VideoWarning: Unexpected MPEG2 start code 00000118 skipped
FileInfo: Last video errors span 34 bytes at file offset 4819097163
VideoWarning: Unexpected MPEG2 start code 0000011a skipped
FileInfo: Last video errors span 24 bytes at file offset 4819097197
VideoWarning: Unexpected MPEG2 start code 0000011b skipped
FileInfo: Last video errors span 27 bytes at file offset 4819097221
VideoWarning: Unexpected MPEG2 start code 0000011c skipped
FileInfo: Last video errors span 39 bytes at file offset 4819097252
VideoWarning: Unexpected MPEG2 start code 0000011d skipped
FileInfo: Last video errors span 35 bytes at file offset 4819097291
VideoWarning: Unexpected MPEG2 start code 0000011e skipped
FileInfo: Last video errors span 36 bytes at file offset 4819097326
VideoWarning: Unexpected MPEG2 start code 0000011f skipped
FileInfo: Last video errors span 39 bytes at file offset 4819097362
VideoWarning: Unexpected MPEG2 start code 00000120 skipped
FileInfo: Last video errors span 66 bytes at file offset 4819097401
VideoWarning: Unexpected MPEG2 start code 00000121 skipped
FileInfo: Last video errors span 32 bytes at file offset 4819097471
VideoWarning: Unexpected MPEG2 start code 00000123 skipped
FileInfo: Last video errors span 26 bytes at file offset 4819097503
VideoWarning: Unexpected MPEG2 start code 00000124 skipped
FileInfo: Last video errors span 18 bytes at file offset 4819097529
VideoWarning: Unexpected MPEG2 start code 00000125 skipped
FileInfo: Last video errors span 28 bytes at file offset 4819097547
VideoWarning: Unexpected MPEG2 start code 00000126 skipped
FileInfo: Last video errors span 30 bytes at file offset 4819097575
VideoWarning: Unexpected MPEG2 start code 00000120 skipped
FileInfo: Last video errors span 42 bytes at file offset 4819097605
VideoWarning: Unexpected MPEG2 start code 00000128 skipped
FileInfo: Last video errors span 24 bytes at file offset 4819097651
VideoWarning: Unexpected MPEG2 start code 00000129 skipped
FileInfo: Last video errors span 23 bytes at file offset 4819097675
VideoWarning: Unexpected MPEG2 start code 0000012a skipped
FileInfo: Last video errors span 21 bytes at file offset 4819097698
VideoWarning: Unexpected MPEG2 start code 0000012b skipped
FileInfo: Last video errors span 31 bytes at file offset 4819097719
VideoWarning: Unexpected MPEG2 start code 0000012c skipped
FileInfo: Last video errors span 39 bytes at file offset 4819097750
VideoWarning: Unexpected MPEG2 start code 0000012d skipped
FileInfo: Last video errors span 63 bytes at file offset 4819097789
VideoWarning: Unexpected MPEG2 start code 0000012e skipped
FileInfo: Last video errors span 71 bytes at file offset 4819097856
VideoWarning: Unexpected MPEG2 start code 0000012f skipped
FileInfo: Last video errors span 60 bytes at file offset 4819097927
VideoWarning: Unexpected MPEG2 start code 00000130 skipped
FileInfo: Last video errors span 60 bytes at file offset 4819097987
VideoWarning: Unexpected MPEG2 start code 00000131 skipped
FileInfo: Last video errors span 51 bytes at file offset 4819098051
VideoWarning: Unexpected MPEG2 start code 00000132 skipped
FileInfo: Last video errors span 56 bytes at file offset 4819098102
VideoWarning: Unexpected MPEG2 start code 00000133 skipped
FileInfo: Last video errors span 21 bytes at file offset 4819098158
VideoWarning: Unexpected MPEG2 start code 00000134 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819098179
VideoWarning: Unexpected MPEG2 start code 00000135 skipped
FileInfo: Last video errors span 14 bytes at file offset 4819098195
VideoWarning: Unexpected MPEG2 start code 00000136 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819098209
VideoWarning: Unexpected MPEG2 start code 00000137 skipped
FileInfo: Last video errors span 25 bytes at file offset 4819098221
VideoWarning: Unexpected MPEG2 start code 00000138 skipped
FileInfo: Last video errors span 12 bytes at file offset 4819098246
VideoWarning: Unexpected MPEG2 start code 00000139 skipped
FileInfo: Last video errors span 37 bytes at file offset 4819098258
VideoWarning: Unexpected MPEG2 start code 0000013a skipped
FileInfo: Last video errors span 14 bytes at file offset 4819098295
VideoWarning: Unexpected MPEG2 start code 0000013c skipped
FileInfo: Last video errors span 52 bytes at file offset 4819098309
VideoWarning: Unexpected MPEG2 start code 0000013d skipped
FileInfo: Last video errors span 44 bytes at file offset 4819098361
VideoWarning: Unexpected MPEG2 start code 0000013e skipped
FileInfo: Last video errors span 60 bytes at file offset 4819098409
VideoWarning: Unexpected MPEG2 start code 0000013f skipped
FileInfo: Last video errors span 76 bytes at file offset 4819098469
VideoWarning: Unexpected MPEG2 start code 00000140 skipped
FileInfo: Last video errors span 104 bytes at file offset 4819098545
VideoWarning: Unexpected MPEG2 start code 00000141 skipped

Sequence Frame 63070(9-B) / Time 0:35:04 :
AudioError: Corrupted AC3 frame of 1534 payload bytes at file offset 4819178674

Sequence Frame 63071(10-B) / Time 0:35:04 :
AudioError: Corrupted AC3 frame of 1534 payload bytes at file offset 4819251994

Sequence Frame 72123(5-P) / Time 0:40:06 :
VideoError: Invalid frame_motion_type for macroblock. MBA=5282(32,704)
VideoError: Failed to decode macroblock at MBA=5282(32,704)
FileInfo: Last video errors span 1441 bytes at file offset 5511531338

Sequence Frame 96754(0-B) / Time 0:53:48 :
VideoError: MPEG2 Intra DCT coefficient index out of bounds. MBA=5650(160,752)
VideoError: Failed to decode macroblock at MBA=5650(160,752)
VideoError: Missing 2511 macroblocks in picture slice(s) at MBA=5649(144,752).
FileInfo: Last video errors span 728 bytes at file offset 7393679248

Sequence Frame 96759(8-P) / Time 0:53:48 :
AudioError: Corrupted AC3 frame of 1534 payload bytes at file offset 7393836042

Sequence Frame 96760(6-B) / Time 0:53:48 :
AudioError: Corrupted AC3 frame of 1534 payload bytes at file offset 7393878906

Sequence Frame 110647(8-P) / Time 1:01:31 :
VideoError: Invalid motion vector code. MBA=7149(1104,944)
VideoError: Invalid motion vector code. MBA=7149(1104,944)
VideoError: Failed to decode macroblock at MBA=7149(1104,944)
FileInfo: Last video errors span 242 bytes at file offset 8455229358

Sequence Frame 138524(8-P) / Time 1:17:02 :
VideoError: Too many macroblocks in slice. MBA=1680(0,224)
FileInfo: Last video errors span 19 bytes at file offset 10585140103

Sequence Frame 183077(4-B) / Time 1:41:48 :
VideoError: Invalid frame_motion_type for macroblock. MBA=3154(544,416)
VideoError: Failed to decode macroblock at MBA=3154(544,416)
FileInfo: Last video errors span 430 bytes at file offset 13988824331

Sequence Frame 187029(14-P) / Time 1:44:00 :
VideoError: Invalid frame_motion_type for macroblock. MBA=5618(1568,736)
VideoError: Failed to decode macroblock at MBA=5618(1568,736)
FileInfo: Last video errors span 164 bytes at file offset 14290870615

Sequence Frame 233311(0-I) / Time 2:09:44 :
VideoError: Invalid Huffman code in intra MPEG2 block. MBA=7801(16,1040)
VideoError: No start code at end of slice. MBA=7801(16,1040)
VideoError: Failed to decode macroblock at MBA=7801(16,1040)
VideoError: Missing 360 macroblocks in picture slice(s) at MBA=7800(0,1040).
FileInfo: Last video errors span 35 bytes at file offset 17827451909

Sequence Frame 233312(0-I) / Time 2:09:44 :
Info: End of MPEG2 sequence

Sequence Summary:

File Size Processed: 16.60 GB, Play Time: 02h:09m:44s
1920 x 1080, 29.97 fps, 17.00 Mbps (16.98 Mbps Average).
Average Video Quality: 69.14 KB/Frame, 0.27 Bits/Pixel.
AC3 Audio: 3/2 Channels (L, C, R, SL, SR) + LFE, 48.0 kHz, 384 kbps.
Dialog Normalization: -24.0 dB, Center Mix Level: -3.0 dB, Surround Mix Level: -3.0 dB
12 of 233312 video frames found with errors.
5 of 243260 audio frames found with errors.
7320 corrupted video bytes in file.
0.000000 seconds of video timestamp gaps.
0.000000 seconds of audio timestamp gaps.

End of Log

The overall bitrate of the file is 18Mbps so I assume that’s why I’m having issues since Infuse won’t exceed ~15Mbps.
Now, I use Plex as well and the bitrates it handles is much larger (confirmed by my network monitoring)
Any idea why the app doesn’t use more bandwidth?

fdsjkhfadjklasfjaklds.png833×624 33 KB

james · November 25, 2017, 5:02pm

Are you using an ATV4 or ATV4K?

There is limited support for interlaced 1080 content on Apple TV 4, but these will play much better on the Apple TV 4K.

_dstrukt.n1ne · November 25, 2017, 5:04pm

ATV4.

But Plex can stream at a higher bitrate without transcoding the video

james · November 25, 2017, 5:08pm

The issue here is the interlaced nature of the video. This unfortunately isn’t supported by the hardware decoder, and will need to be played in software - which is slower.

I believe transcoding would be required in Plex for this video.
